Technical Characteristics
Auto water cooling platform combines with environmental LED cold solicified technology, ensuring fine printing on heat sensitive media without deformation.
Printer is designed for industrial purpose and assembled with four rubber rollers feeding system, heavy duty body for longer life and stability.
Enhanced structure is equipped with double THK guide rail, magnetic levitation motor system for high precision printing.
Efficient up-down tension system guarantee media feeding without winkle. Strong take up system can fit media rolls more than 200kgs.
Technical Specifications
| Model |
| FR5300UV | FR3300UV |
| Print Head | Print head QTY | KM1024i head 4~18pcs | 4~18pcs |
| Ink | Color Ink type Ink supply | C/M/Y/K/LC/LM/W UV ink Negative pressure ink supply | C/M/Y/K/LC/LM/W |
| Speed | Production mode Quality mode Photo mode | 104 m2/h ~ 108 m2/h 82 m2/h ~ 86 m2/h 56 m2/h ~ 60 m2/h | 86 m2/h ~ 90 m2/h 68 m2/h ~ 72 m2/h 46 m2/h ~ 50 m2/h |
| Media | Dimension Media type Media transfer | 5000mm Soft film lightbox, light cloth, PVC banner, car stickers, textile fabrics and other printed materials Roller feeding | 3200mm |
| Cleaning |
| Positive pressure cleaning device |
|
| Rip Software |
| ONYX |
|
| Curing System |
| UV LED Lamp |
|
| File Format |
| Tiff, Jpeg, Postscript,Eps, Pdf |
|
| Interface |
| USB |
|
| Working Environment |
| Temperature: 18℃-30℃, Humidity : 30%-80% |
|
| Power Supply |
| Frequency. 50HZ/60HZRated voltage: AC220V (±10%) |
|
| Machine Size |
| L7500 × W1600 × H2000 (mm) | L5500 × W1600 × H2000 (mm) |
| Machine Weight |
| 6500Kg | 4550Kg |
| Warranty |
| 1 year |
|
