Technical Characteristics
The machine adopts belt feeding system, it can compatible with soft and hard media, thick and thin media, compatible with more printing materials expanding your business.
Equipped with 3 or 6 piezoelectric heads for CMYK, W and Vanish, Multi printing mode for options, C/W+C/ C+W+C/W+C+V/Embossed effect. this printing solution can be applied to more industries to ensure the best performance of equipment investment.
Benefiting from the environmental trends of LED cold solidified technology, the machine achleves longer life, lower energy consumption, There is almost no ozone when printing.
The UV ink we used contains of almost no VOC, which is better for the environment during the whole working time
The machine adopts moulds and high precision CNC parts to ensure the precision of the whole machine, to ensure the high level of printing quality.
Nearly ten years experience of electrical machinery, ink transmission, design and manufacturing in printing area, to ensure the machine stability.
Equipped with crash sensor and anti-static device.
Solid THK mute guide rail.
High precision belt feeding system, duriable & friendly to elastic media.
Technical Specifications
Model | HB-1603UV | HB-1606UV | |
Print Head | Print head QTY | i3200U1 3pcs | i3200U1 6pcs |
Ink | Color Ink type | C/M/Y/K/LC/LM/W UV ink | C/M/Y/K/LC/LM/W |
Speed | Draft mode Precision Photo | 12 m2/h (CMYK+W+V+CMYK) 10 m2/h (CMYK+W+V+CMYK) 8 m2/h (CMYK+W+V+CMYK) | 24 m2/h (CMYK+W+V+CMYK) 20 m2/h (CMYK+W+V+CMYK) 16 m2/h (CMYK+W+V+CMYK) |
Media | Dimension Printing size Media type Media transmission | 1550mm 1520mm PET、PVC,Leather,Banners,Rigid Medias Mesh belt feeding system | |
Rip Software | Photoprint | ||
Curing System | UV LED Lamp | ||
File Format | Tiff, Jpeg, Postscript,Eps, Pdf | ||
Cleaning | Automatic cleaning device | ||
Interface | USB | ||
Working Environment | Temperature: 18℃-29℃, Humidity : 50%-80% | ||
Power Supply | Frequency: 50HZ/60HZ Power : Maximum 7500W Rated voltage: AC220V (±10% | ||
Machine Size | L3300 x W1500 x H1500(mm) | ||
Machine Weight | 850Kg | ||
Warranty | 1 year |
